ELISA
The enzyme-linked immunosorbent assay (ELISA) uses the exquisite specificity of an antibody–antigen bond to detect and quantify a target, reading it out as a color change driven by an enzyme. Run in 96-well plates, it is the workhorse of serosurveillance (measuring who has antibodies to a pathogen) and of antigen detection, cheap and scalable enough to process thousands of samples a day.
The core idea and the main formats
Every ELISA immobilizes something on the plate, washes away everything that does not stick, and detects what remains with an enzyme-conjugated antibody that converts a colorless substrate into a colored product. The optical density (OD) measured by a plate reader is proportional to how much target was captured.
- Direct — antigen on the plate, detected by a single enzyme-labeled antibody.
- Indirect — antigen on the plate, detected by a patient antibody, then an enzyme-labeled anti-species secondary antibody. This is the standard format for antibody/serology testing.
- Sandwich — a capture antibody on the plate grabs the antigen, and a second labeled antibody detects it. Highly specific for antigen detection.
- Competitive — sample analyte competes with a labeled reference; here more signal means less analyte, useful for small molecules.
Turning optical density into concentration
OD does not rise linearly with concentration — it saturates. The standard model for an ELISA calibration curve is the four-parameter logistic (4PL):
where is the bottom (blank) signal, is the top (saturation), is the EC50 (the concentration at the inflection point), and is the Hill slope. You fit the 4PL to a dilution series of known standards, then invert it to read unknown concentrations off their ODs. Reliable quantification is only possible within the curve’s dynamic range — samples above saturation must be diluted and re-run.
Cutoffs for qualitative serology
For yes/no serosurveys the readout is dichotomized with a cutoff, often set from a panel of known negatives (e.g. mean + 3 SD of the negative controls). Every cutoff trades sensitivity against specificity, and because seroprevalence surveys often run at low true prevalence, even a small false-positive rate can dominate the positives — which is why raw seroprevalence is usually adjusted for assay performance.
A worked example
We fit a 4PL curve to a seven-point standard series and back-calculate the concentration of an unknown from its OD.
In code
R
fourpl <- function(x, a, d, c, b) d + (a - d) / (1 + (x / c)^b)
conc <- c(1, 3, 10, 30, 100, 300, 1000)
od <- c(0.06, 0.12, 0.34, 0.98, 1.9, 2.7, 3.1)
fit <- nls(od ~ fourpl(conc, a, d, c, b),
start = list(a = 0.05, d = 3.2, c = 30, b = 1))
coef(fit) # bottom, top, EC50, Hill slope
Python
import numpy as np
from scipy.optimize import curve_fit
def fourpl(x, a, d, c, b):
return d + (a - d) / (1 + (x / c) ** b)
conc = np.array([1, 3, 10, 30, 100, 300, 1000.0])
od = np.array([0.06, 0.12, 0.34, 0.98, 1.9, 2.7, 3.1])
(a, d, c, b), _ = curve_fit(fourpl, conc, od, p0=[0.05, 3.2, 30.0, 1.0], maxfev=10000)
print(f"bottom={a:.2f} top={d:.2f} EC50={c:.1f} ng/mL hill={b:.2f}")
# invert the curve to read an unknown OD back to a concentration
od_unknown = 1.2
conc_unknown = c * ((a - d) / (od_unknown - d) - 1) ** (1 / b)
print(f"OD {od_unknown} -> {conc_unknown:.1f} ng/mL")
bottom=0.01 top=3.30 EC50=73.0 ng/mL hill=1.04
OD 1.2 -> 42.4 ng/mL
Julia
using LsqFit
fourpl(x, p) = p[2] .+ (p[1] .- p[2]) ./ (1 .+ (x ./ p[3]) .^ p[4])
conc = [1, 3, 10, 30, 100, 300, 1000.0]
od = [0.06, 0.12, 0.34, 0.98, 1.9, 2.7, 3.1]
fit = curve_fit(fourpl, conc, od, [0.05, 3.2, 30.0, 1.0])
fit.param # bottom, top, EC50, Hill slope
Trade-offs & resource considerations
- Sensitivity & specificity. Good, and tunable through the cutoff, but bounded by the quality of the antibody reagents and by cross-reactivity — antibodies raised against one pathogen may bind a related one, inflating false positives.
- Cost. Moderate: a plate reader (a few thousand dollars), plates, and antibody/conjugate reagents. Per-sample cost is low once the platform is in place, which is why ELISA scales for large serosurveys.
- Training & infrastructure. A standard immunology-lab technique — pipetting accuracy, wash steps, and plate-to-plate controls matter, and results drift without careful standardization across batches and operators.
- Turnaround. Hours per plate, in batches.
- Quantitative discipline. Every plate needs its own standard curve and controls; comparing raw ODs across plates without recalibration is a common and serious error.
Why it matters
ELISA is how we measure population immunity. Serosurveys built on ELISA tell us what fraction of a population has been infected or vaccinated — the susceptible pool that drives whether transmission can be sustained — and antigen-capture ELISAs detect active infection where a rapid test is not sensitive enough.
